Automatic Packaging Machines

Chips Packing Machine offered by us has a number of advanced features. This machine has 14 head and 10 head weigh fillers that have - / + 0.1% filling accuracy. It uses center seal type sealing technique. Accessible in single phase design, this system is capable of packing maximum 60 bags per minute. This machine is driven by AC power and it has single phase structure. Its power requirement is 3 kw. This Chips Packing Machine has 72" x 85" x 126 size and its approximate weight is 1400 kg. This system is accessible with optional batch coding device.

Specification

This heavy duty Dry Fruits Packing Machine uses PP/PE/laminated film as its raw material. This machine is capable of producing stand up type, flat type, spout and stand up with zipper based packaging bags. Produced bags have maximum 200 mm width and up to 350 mm length. Maximum filling accuracy of this machine is 1.5%.  Available in three phase design, this Dry Fruits Packing Machine consumes 380 v voltage. Frequency of this machine ranges between 50 Hz to 60 Hz.

Specification

• Working position: Six-working position
• Bag material: Laminated film/PE/PP
• Bag pattern: Stand-up with zipper & stand-up, spout, flat bag,
• Max filling weight: 10-5000g
• Filling accuracy: 0.5-1.5%
• Bag size: W:100-200mm L:100-350mm (could be customized)
• Speed: 10-60bags/min
• Voltage: 380v 3phase 50/60hz
• Total power: 5.5KW
• Compress air: 0.6m³/min

Specification

• Working position: Six-working position
• Bag material: Laminated film/PE/PP
• Bag pattern: Stand-up with zipper & stand-up, spout, flat bag,
• Max filling weight: 10-5000g
• Filling accuracy: 0.5-1.5%
• Bag size: W:100-200mm L:100-350mm (could be customized)
• Speed: 10-60bags/min
• Voltage: 380v 3phase 50/60hz
• Total power: 5.5KW
• Compress air: 0.6m³/min

This Namkeen Packing Machine uses volumetric cup filler based mechanism. Its packaging range is maximum 500 gram to 1000 gram. Its center seal based mechanism is effective in packing and sealing of packed grains and powder. This machine uses laminated film as its raw material. Driven by AC power, this system can handle maximum 60 bags per minute. Dimension of this machine is 1050 mm x 990 mm x2100 mm and it weighs 750 kg. Provided Namkeen Packing Machine is offered with optional gas flushing unit, batch cutting and batch coding units.

Specification

• Packing Range: 1.(20gm to100gm) 2.(100gm to 500gm) 3.(500gm to 1000gm)
• Filling System: Volumetric Cup Filler
• Type of Sealing: Center Seal
• Packing Material: Powder, Grains, Etc
• Film Size: 200mm-420mm width x 100mm-550mm length
• Film Roll Size: OD 250 to 400mm max. ID film reel pipe 75mm
• Film Roll Type: Laminated Film
• Speed: 40 to 60 bag/min (Varies with the nature of product & Filling range)
• Power: 3 KW 230V / AC / Single Phase/ 50hz
• Optional: Batch Coding Device, Batch Cutting Device Gas Flushing
• Wooden Case: 1700mm x 1000mm x 1100mm (H x W x L))
• Machine Size: 1050mm x 990mm 2100(L x W x H)
• Machine Weight: 750kg. (Approx)

Single phase PULSES PACKING MACHINE is reckoned for its high production capacity. Featured with center seal type technology, this machine is appreciated for its high speed operation. This equipment can pack maximum 60 bags per minute. Driven by AC power, this system is accessible with optional batch cutting/batch coding device. Its packaging range is 100 gram to 500 gram, 20 gram to 100 gram and 500 gram to 1000 gram. Offered PULSES PACKING MACHINE weighs 750 kg. This machine is user friendly.

Specification

• Packing Range: 1.(20gm to100gm) 2.(100gm to 500gm) 3.(500gm to 1000gm)
• Filling System: Volumetric Cup Filler
• Type of Sealing: Center Seal
• Packing Material: Powder, Grains, Etc
• Film Size: 200mm-420mm width x 100mm-550mm length
• Film Roll Size: OD 250 to 400mm max. ID film reel pipe 75mm
• Film Roll Type: Laminated Film
• Speed: 40 to 60 bag/min (Varies with the nature of product & Filling range)
• Power: 3 KW 230V / AC / Single Phase/ 50hz
• Optional: Batch Coding Device, Batch Cutting Device Gas Flushing
• Wooden Case: 1700mm x 1000mm x 1100mm (H x W x L))
• Machine Size: 1050mm x 990mm 2100(L x W x H)
• Machine Weight: 750kg. (Approx)

This single phase Chikki Packing Machine uses food grade packaging material. Maximum length of produced bag is 280 mm and width is up to 110 mm. Energy efficient motor of this machine reduces its production duration. Operating speed of this system ranges between 40 rpm to 230 rpm. Its diameter is 1800mm L 1000mm W 1360mm H and approximate weight is 700 kg. Offered Chikki Packing Machine is well known for its user friendly mechanism, quick installation process and low maintenance charge.

Specification

• Model: HFFS 250
• Max Film Width: 250mm
• Bag Length: 65mm - 190mm 120mm - 280mm
• Bag Width: 30mm-110mm
• Max Product Height: 40mm 55mm
• Speed: 40-230 PPM
• Power: MOTOR 1 H.P 2.5KW SINGLE PHASE
• Machine Size: 1800mm L x 1000mm W x 1360mm H
• Machine Weight: 700kg (Appx.)

This Automatic Rotary Snacks Pouch Packing Machine uses PP/PE or laminated film for producing pouches. Manufactured pouches have spout, stand up, flat type and stand up with zipper based design. Maximum filling weight of this machine ranges between 10 gram to 5000 gram. This machine can maintain up to 1.5% filling accuracy. Provided Automatic Rotary Snacks Pouch Packing Machine is capable of producing maximum 60 bags in every minute. This three phase system consumes 380 v voltage and its frequency ranges between 50 Hz to 60 Hz.

Specification

• Working position: Six-working position
• Bag material: Laminated film/PE/PP
• Bag pattern: Stand-up with zipper & stand-up, spout, flat bag,
• Max filling weight: 10-5000g
• Filling accuracy: 0.5-1.5%
• Bag size: W:100-200mm L:100-350mm (could be customized)
• Speed: 10-60bags/min
• Voltage: 380v 3phase 50/60hz
• Total power: 5.5KW
• Compress air: 0.6m³/min
